Item no. | Dim.Code | WLL | Dim mm | kg | |||
4:1 ton | d | b | B | L | N.W. | ||
0301201 | 13.A.6 | 2.4 | 13 | 30 | 60 | 120 | 0.4 |
0301202 | 16.A.6 | 3.8 | 16 | 35 | 70 | 130 | 0.6 |
0301203 | 20.A.7 | 5.8 | 20 | 45 | 90 | 180 | 1.3 |
0301204 | 22.A.6 | 7.6 | 22 | 45 | 90 | 180 | 1.6 |
0301205 | 25.A.6 | 10 | 25 | 50 | 100 | 200 | 2.3 |
0301206 | 28.A.6 | 12.7 | 28 | 55 | 110 | 220 | 3.2 |
0301207 | 32.A.6 | 15.2 | 32 | 70 | 140 | 285 | 5.3 |
0301208 | 38.A.6 | 25 | 38 | 70 | 140 | 285 | 7.6 |
0301209 | 45.A.6 | 34 | 45 | 85 | 170 | 340 | 12.5 |
0301210 | 50.A.6 | 40 | 50 | 100 | 200 | 400 | 18.0 |
