| Max pulling capacity / empty drum: | 45 kN (4,5 tons) |
| Max pulling capacity / full drum: | 17,5 kN (1,75 tons) |
| Number of drums: | 1 |
| Wire rope, theoretical capacity: | 73 m, 10 mm |
| Recommended wire rope length: | 60 m, 10 mm |
| Pulling speed at 540 rpm: | 0,67 – 1,66 m/s |
| Ratio: | 1 : 5,18 |
| Necessary power input: | 29 kW |
| Braking power: | Min 56 kN (5,6 tons) |
| Controls: | Standard cord operation |
| Clutch: | Replaceable friction pads |
| Brake: | Ratchet brake |
| Mounting: | 3-punkt |
| PTO input, distance from ground: | 50 cm |
| Height/ Width/ Depth: | 192/ 152/ 61 cm |
| Weight (without wire rope): | 260kg |
1 in Stock
